The AIRLAB MK2 radio ON-AIR console is an extremely reliable solution for applications where features and functions has to be weighed up against operational simplicity. It's analog, digitally controlled signal path is the best solution of both worlds to achieve a reliable workhorse under any condition. With over 600 units in the field, the Airlab MK2 has proven to be a successful centerpiece of your ON-Air studio.

A simple direct accessible control surface combined with intelligent instantly reset able digital functions enables customizing to station requirements and even to personal requirements because of the use of a personalized chip card holding all important functional data.

Purchasing choices are straightforward: the welded steel frame will accommodate a maximum of 16 triple input modules, which could include an unlimited number of Telco modules (up to 16 of course) plus the master section with script space. The main outputs are electronically balanced and the majority of connectors are on balanced XLRs.

Air lab Digital version is also Available….


Broadcast Audio Products Netherlands

With the AIRENCE-USB ON-AIR mixer you can own a modern, split version type of radio production mixer. A smart mixer with an integrated USB based control section. Built with well proven low noise circuitry, this console is the reliable workhorse for the self-op production D.J. Built in Telephone Hybrids (2x), 4 channels USB and 4 Mic inputs. Ideal for streaming to the web and sending and accepting 4 stereo channels from your Play-out software.

A heavy duty (19" rack) RF shielded chassis, that can be used as a drop through in your furniture, houses all the vertically mounted input modules. Extension units with six triple input channels with high end quality Mic inputs on XLR and two stereo line level inputs on Cinch (RCA) connectors can be connected to the main unit. The result is a modern split drop through 12 (or 18/24) fader radio console.





The Lyra is a fully digital desktop production mixer. Its concept originates from heavy investigations among end users and distributors looking for a versatile compact small universal desktop mixer.

The core of the Lyra is a sophisticated DSP engine. This processing engine involves the latest developments in DSP technology by Texas Instruments. An intense cooperation between T.I. and D&R has resulted in a digital audio mixer offering tremendous DSP power and a superb sonic quality. Although the Lyra is a digital console, it is operated with the same comfort as a conventional analog production mixer. No fundamental concessions have been made towards reliability, high speed controller-response and system stability. Apart from that there is the unique capability to control Lyra's functions over the Internet.

4 and 8 fader control surfaces available….













This new Airmate-USB model has 6 balanced mic inputs (+48 phantom is standard) with insert, 12 stereo line inputs, 2x USB and 2x Telephone Hybrids.

Channel 5 and 6 have Mic/Line and USB interface to transfer audio from and to your PC.

Channel 7 and 8 have, apart from the stereo line input, also RJ-11 connectors to interface with a POT (Plain Old Telephone) line and a Telephone appliance to dial the number you want to reach.

High quality built in Hybrids with R (trimmer on the surface) and C balance (switch on the surface) and direct Connection and Talkback buttons in the Hybrid channels makes a conversation with listeners very easy. With the Telco Send (level to the caller) and Telco Gain (level coming from the caller) all levels can be easy adjusted.















More info Click>>>    http://www.d-r.nl/airmate-usb.html

More info Click>>>    http://www.d-r.nl/lyra.html

More info Click>>>     http://www.d-r.nl/airence-usb.html

More info Click>>>   http://www.d-r.nl/airlab.html

The AXUM VERSION 3.0 is a modular completely preprogrammed platform that can grow with you and your organization any time, any moment.    I/O cards can be shared between systems and a Broadcast station that has decided to use the AXUM as their main and support mixers can be sure to have invested in a future proof product.

The Axum can be used for small local 4 fader desktop use as well as large scale (128 faders max) production work and everything in between.    A large matrix of 1280x1280 with extensive signal processing on a maximum of 128 stereo channels is available that can be assigned to Sixteen stereo summing mixing busses and sixteen monitor buses as well as directly between the maximum of 4 DSP's.



More info Click>>>   http://www.d-r.nl/axum.html

 The Vis ion is the newest addition to D&R's collection of high quality consoles . A progressive sound reinforcement/recording and television Sound console. Designed for the most discriminating live sound and studio engineers. The Vision can fit into many different sound environments.

 The D&R design team choose high quality components and manufacturing techniques for the Vision, such as socket mounted Analog  Dev ices active components and ALPS or P&G potentiometers and faders and silver plated switches as well as glass epoxy printed circuit boards (plated  on both sides where necessary).

 The Vis ion i s available in 3 frame sizes ranging from 19" rack mount (will hold 12 modules) up to a full 44 input version. The Vision can be specified with the standard master module plus any combination of input and group modules. In addition , a d e l u x e m a s t e r m o d u l e i s available with extra features.  Due to the many different requirements in live sound TV and recording applications , D&R designed several different types of modules.        http://www.d-r.nl/vision.html





More info Click>>>          http://www.d-r.nl/vision.html
